JIC Bevel Seat Fittings
Female JIC Swivel
- Joint Industrial Conference SAEJ514 specification
- 37° JIC metal-to-metal sealing
- Male JIC rigid available
- JIC Part # Example:
FJX-08-SS
FJX = JIC Female Swivel
Sizes Available
- 1/2" - 08
- 3/4" - 12
- 1" - 16
- 1-1/2" - 24
- 2" - 32
Standard Material
- SS - 316 Stainless Steel
- CS - Carbon Steel
Custom Material
- M - Monel®
- H - Hastelloy®
*Mixed combination fittings available: Standard - Nut and insert same material; Combination - Nut and insert different. Example: Hastelloy® insert with 316 SS nut
