CTH - Chlorine Transfer Hose, Convoluted Teflon®
- Conductive, heavy wall Teflon® PTFE liner
- Self cleaning open pitch helical convolutions
- Seamless vacuum formed liner
- Hastelloy® C276 braid
- Monel NPT Fittings
- Standard HDPE outer armor guard
- Flange and CGA 820 fitting options
Benefits:
- Meets Chlorine Institute recommendations
- 5:1 safety factor for Burst Pressure
- Extreme inner and outer corrosion protection
- Very kink resistant
- light weight abrasion resistant armor guard
Applications:
- Specifically designed for manufacturing, transporting, and packaging of chlorine and bromine
Connections:
- Flanged
- NPT
| Nominal Size | ID | OD | Bend Radius | Working Pressure @ 70°F | Burst Pressure @ 70°F | Part Number | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inch | DN | Inch | MM | Inch | MM | Inch | MM | PSI | BAR | PSI | BAR | |
| 1/2 | 15 | 0.470 | 11.9 | 0.748 | 19.0 | 2 | 50.8 | 500 | 34.5 | 2500 | 172.4 | consult sales |
| 1 | 25 | 0.970 | 24.6 | 1.354 | 34.4 | 4 | 101.6 | 500 | 34.5 | 2500 | 172.4 | consult sales |
| 1-1/2 | 40 | 1.540 | 39.1 | 2.034 | 51.7 | 6 | 152.4 | 375 | 25.9 | 1875 | 129.3 | consult sales |
NOTE: In an assembly, the pressure ratings of fittings may be less than hose pressure ratings.
